MRV-21
RADAR & Vision fusion ADAS system
World first RADAR-camera integrated ADAS system which can be mounted behind the windshield
Main functions
- Pedestrian Collision Warning (PCW)
Notifies driver of any pedestrians,
bicycles or motorcycles ahead. - Front Vehicle Start Alarm (FVSA)
Notifies driver if the front vehicle started moving
forward from 0 speed without the vehicle moving
within 2 secs. - Forward Collision Warning (FCW)
Sends warning alerts if a crash is imminent to
assist driver in maintaining a safe traveling
distance.
# Heavy Rain & Fog
Consistent FCW performance even
at heavy rain, severe snow and thick fog.
# Motorcycle & Cyclists
Show excellent performance to detect and
track motorcycles and cyclists - Forward Proximity Warning (FPW)
Notifies driver if the front vehicle started moving
forward from 0 speed without the vehicle moving
within 2 secs.
- Lane Departure Warning (LDW)
Helps to regain direction if the driver
unintentionally departs lanes.
- Digital Video Recorder (DVR)
Records scenes as HD resolutions. Continuous/
Event & User Triggering Record Mode
Product Specification
| CPU |
Coretex A7 Quad Core |
|---|---|
| Vision Sensor |
Camera: 1280 ⅹ720 (HD) |
| Radar Sensor |
RF: 76~77GHz |
| Power |
DC 10~36V |
| Input / Output |
Micro 5PIN USB Port |
| Audio |
Built in Speaker |
| Temperature |
Operation | -20 ℃ ~ 70℃ (-4℉ ~ 158℉) |
Camera & Radar Fusion Algorithm
World first camera & radar fusion ADAS
-
Camera & radar sensors in one system
Fusion algorithm provides the most accurate data to the system
Sensor fusion is a key to improve the weakness of each sensors
All weather safe solution such as direct sunlight, dark night, heavy rain, snow, dust and foggy weather. -
Camera Sensor
Radar Sensor
How the fusion ADAS system works
Easy installation on windshield
In-Cabin install radar system
1min. Installation: Simply put Camera & radar on your vehicle windshield. No hassle to open bumper.
Auto-calibration feature reduce time to calibrate the unit.
Available for all types of vehicle such as passenger vehicle, truck, van and buses.
DVR Features
Dashcam Features
Recording High definition (HD) video continuously
Event Mode: Only events are recorded
User Mode: Users are able to initiate recording
Viewer allows recordings to be seen with ADAS information detected
Easy to integrate with FMS platform
FMS Ready solution
Easy to integrate with your fleet management platform
Available by RS-232 or CAN
Data saving protocolsminimize the data format and reduce telecommunication cost
Transmit the video, snapshots and the various data
